The RGB Round Touch Light Module is a smart, elegant lighting solution designed for interactive furniture, river tables, and embedded decor. Featuring a color-changing RGB LED strip, this module senses touch through non-metallic surfaces such as resin, wood, acrylic, and plastic up to 3 cm thick—ideal for clean, hidden lighting effects.

The module defaults to DC 5V, but supports 12V operation when paired with a compatible 12V RGB LED strip. Installation is fast and simple: plug in the XH2.54 3P connector, attach your RGB LED strip, and you’re ready to illuminate your project.

Touching the surface above the sensor triggers the full RGB light display, which remains active as long as touch is detected. Upon release, the lights fade gently. With almost no heat generation and low power consumption, this module is safe and efficient—but it is not recommended for continuous or long-term unattended use.

Features:
Touch-sensitive RGB LED lighting module

Supports vibrant color-changing LED strips (4P RGB)

Operates on 5V DC by default, or 12V with compatible RGB strip

Almost no heat, low energy use

Easy plug-and-play setup—no configuration required

Sensitive through non-metallic surfaces up to 3 cm thick

Ideal for resin, wood, acrylic, plastic, and more (not compatible with metal)

Specifications:
Product Name: RGB Round River Light Module

Trigger Mode: Touch switch

Input Voltage: DC 5V (Supports 12V with matching RGB LED strip)

Power Supply Interface: XH2.54 3P plug

LED Output Voltage: Default DC 5V (Use 12V strip with 12V input)

Max Current: ≤120mA

Module Size: 40mm x 38mm x 10mm

RGB LED Strip Length: ~20cm (optional)

Usage Instructions:
Plug the 4P RGB LED strip socket into the module.

Connect the power supply via the XH2.54 3P plug.

LED will glow dimly in standby mode.

Touch the sensor area to activate full brightness.

Release the touch to fade the LEDs off gently.

Package Includes:
1 x RGB Round Touch Sensor Module

1 x RGB LED Strip (Optional)

Ring Touch Sensor Module Sale Agreement and Safety Disclaimer
This document serves as a formal agreement and acknowledgment between the Seller and the Purchaser regarding the sale of the Ring Touch Sensor Module (hereinafter referred to as “the Module”).

Kit Form Sale
The Module is sold as an individual component intended for integration into larger electronic or lighting systems. It is not supplied as a fully assembled or certified standalone device, and it is not ready for direct use with household mains electricity without appropriate interfacing and protection.

Electrical Safety Requirements
The Purchaser understands and agrees that:

The Module is designed for use with DC 5V or DC 12V power only. Under no circumstances should it be connected directly to AC mains voltage.

All wiring, power conversion, and system integration must be performed by a qualified technician or electrician, especially in installations where the Module interfaces with other powered components.

The Module should not be left connected to power unattended for extended periods. Unsupervised or continuous operation is not recommended to reduce the risk of overheating or malfunction.

Purchaser’s Acknowledgment
By purchasing or using the Module, the Purchaser confirms that they:

Understand the Module is provided as an electronic component, not a complete or certified consumer device.

Will ensure proper integration, power regulation, and installation by qualified personnel.

Accept full responsibility for the safe handling, installation, and use of the Module, including any associated wiring and enclosures.

Liability Waiver
The Seller shall not be held liable for any injury, damage, or loss arising from misuse, improper installation, electrical fault, or unauthorized modification of the Module. The Purchaser assumes all responsibility for compliance with local safety regulations and best practices in electronic assembly.

By completing the purchase, the Purchaser acknowledges that they have read, understood, and agreed to the terms outlined above.
